Customized Smart battery module RV256100V2-Pro manufacturers From China compared with similar products on the market, it has incomparable outstanding advantages in terms of performance, quality, appearance, etc., and enjoys a good reputation in the market.Zhuocheng summarizes the defects of past products, and continuously improves them. The specifications of Customized Smart battery module RV256100V2-Pro manufacturers From China can be customized according to your needs.
| Electrical Parameters | ||||
Nominal Voltage | 25.6V | |||
| Nominal Capacity | 100Ah | |||
| Discharge Time@50A | 120min | |||
| Internal Resistance | ≤30mΩ@50%SOC | |||
| Efficiency | 99% | |||
| Self Discharge | <3% per month | |||
Maximum Modules in Series/Parallel | 2/8 | |||
| Charge Parameters | |
| Recommended Charge Current | 10A-50A |
| Max Continuous Charge Current | 50A |
| Recommended Charge Voltage | 28.4V-29.2V |
| BMS High Voltage Protection Value | 29.2V(3s) |
| High Voltage Protection Release Value | 27.6V |
| Balance Opening Voltag | 28V |
| Discharge Parameters | |
| Max Continuous Discharge Current | 80A |
| BMS Discharge Protection Current | 200A(5s) |
| Recommended Low Voltage Protection | 24V |
| BMS Low Voltage Protection Value | 22.4V(3s) |
| Low Voltage Protection Release Value | 24.8V |
| Short-Circuit Protection | 200-600(㎲) |
Take advantage of our unrivaled knowledge and experience, we offer you the best customization service.
